Coal Mill


Strong adaptability, reliable performances and continuous production

A coal mill is the important auxiliary equipment for coal-powder furnace. It has three methods to crush the coal lumps and to grind them into powders, that is, crushing, impacting and grinding.
Coal mill is used to grind, pulverize and dry coal before the coal is transmitted the boiler. The coal is fed into the coal mill via an inlet pipe so that the coal mill can pulverize the coal into particles.

Materials:Coal, cement clinker, limestone, calcite, dolomite, talc, etc.

Product Advantages


The use of new wear-resistant materials greatly improves the service life of wearing parts.

The PLC control system can be selected to improve the automation control level of the grinding mill.

The coal mills have closed structure, so there is less dust spill-over, and it is beneficial and friendly to the surrounding environment.

ZENITHS’s coal mills have an excellent balance between productivity and energy consumption. Users can get higher capacity under the premise of low energy consumption.



Working Principle of Coal Mill


As the mill rotates, steel balls work to grind the coal. The mill rotates approximately once every couple of seconds.
The grinding system uses either 'open circuit' or 'closed circuit'. In an open circuit system, the feed rate of coal is adjusted to achieve the desired fineness of the product. In a closed circuit system, coarse particles are separated from the finer ones and sent back for further grinding. When final products reach the fineness standard, they are discharged out of the mill.

Technical Specs


Customer Cases


Oman 300TPH Limestone Crushing Line

Location:Saham, Oman
Material:Limestone
Input Size:Below 720mm
Output Size:0-5mm, 5-10mm, 10-20mm, (Oman standard)
Capacity:300t/h


Russia 50TPH Granite/Dolomite Crushing Line

Location:Russia
Material:Granite, dolomite
Input Size:Below 425mm
Output Size:0-5-10-15-40mm
Capacity:50t/h


Russia 300-350TPH Granite Crushing Line

Location:Russia
Material:Plagiogranite
Input Size:Below 700mm
Output Size:0-5mm, 40-70mm (0-5mm, 5-10mm, 10-20mm)
Capacity:300-350t/h


Congo 150TPH Granite Stationary Crushing Line

Location:Congo
Material:granite
Input Size:Below 500mm
Output Size:0-3mm, 3-6mm, 6-12mm, 12-25mm, 25-40mm
Capacity:150t/h


Jeddah 300TPH Marble Crushing Line

Location:Jeddah
Material:Jeddah
Output Size:0-1mm, 1-4mm, 4-7mm, 7-10mm, 10-14mm, 14-18mm, 18-35mm
Capacity:250-300t/h


Kenya 30-50TPH Phonolite Crushing Line

Location:Awasi, Kenya
Material:Phonolite
Input Size:Below 350mm
Output Size:0-6mm, 6-10mm, 10-28mm
Capacity:30-50t/h
