LM Vertical Grinding Mill


More stable and reliable production and more excellent capacity

The LM Vertical Grinding Mill, launched by ZENITH, integrates five functions of crushing, grinding, powder selection, drying and material conveying. It is characterized by centralized technological process, small occupational area, low investment, high efficiency, energy conservation and environment protection. It is the ideal equipment in the grinding industry.

Materials:Limestone, calcite, dolomite, petroleum coal, gypsum, barite, marble, talc, coal powder, etc.

Product Advantages


LM Vertical Grinding Mill achieves lower energy consumption, stronger drying capacity, as well as lower abrasion and easier checks of core parts, saving operating costs greatly.

Materials linger in the grinding mill for a short time, which can reduce repeated grinding and is easy to detect and control the grain size and chemical component of the product.

The system is sealed in an integral manner and works under negative pressure, so that there is no dust spilling and the environment can keep clean.

Its occupational area is about 50% of that of the ball-milling system. The LM grinding mill can also be arranged outdoors, which greatly reduces the investment cost.

Working Principle of LM Vertical Grinding Mill


The grinding plate rotates under the action of main motor and the reducer. Meanwhile, hot airflow enters the vertical grinding mill. After raw materials fall onto the center of grinding plate, they, under centrifugal force, move to the edge of grinding plate. While passing through the grinding area between roller and grinding plate, large materials are broken directly under the pressure of roller while fine materials form a layer where materials crush each other. Broken materials after grinding continue moving to the edge of grinding plate until they are blown away by the airflow at the air ring. For coarse materials which cannot be brought away would fall onto the grinding plate for another grinding. When passing the upper separator, materials in the airflow will be divided into two parts by the blades of rotor, that is, coarse particles and fine powders. Coarse particles would be sent back to have another grinding while qualified fine powders enter the powder collector with airflow as finished products. For sundries like iron block in materials, when they move to the fringe of grinding plate, because of their heavier weight, they would drop to the lower cavity of grinding mill and next be sent into the discharging port by scarper installed at the bottom of grinding plate and finally be discharged out of the grinding mill.

Technical Specs


Customer Cases


Oman 300TPH Limestone Crushing Line

Location:Saham, Oman
Material:Limestone
Input Size:Below 720mm
Output Size:0-5mm, 5-10mm, 10-20mm, (Oman standard)
Capacity:300t/h


Russia 300-350TPH Granite Crushing Line

Location:Russia
Material:Plagiogranite
Input Size:Below 700mm
Output Size:0-5mm, 40-70mm (0-5mm, 5-10mm, 10-20mm)
Capacity:300-350t/h


Mecca 500TPH Granite Crushing Line

Location:Mecca
Material:Granite
Input Size:Below 1000mm
Output Size:0-10mm, 10-13mm, 13-20mm, 20-25mm
Capacity:400-500TPH (12 hours per day)


Saudi Arabia 600TPH Granite Crushing Line

Location:Saudi Arabia
Material:Granite
Capacity:600t/h


Vietnam 250TPH Limestone Crushing Line

Location:Vietnam
Material:Limestone
Input Size:Below 210mm
Output Size:0-3mm
Capacity:250t/h


Zambia 200TPH Granite Crushing Line

LineLocation:Zambia
Material:Granite
InputSize:Below 650mm
OutputSize:0-15mm,5-9mm,9-19mm,19-23mm
Capacity:200t/h
