Gold Ore Features

Gold ores refer to the minerals having gold elements or gold compounds. Through beneficiation, gold ores can be processed into gold concentrates. Then, through smelting or other methods, users can produce gold products. Because of its special characteristics, gold attracts numerous consumers around the world. It takes an important role in jewelry industry. Besides, investing gold is always an indispensable direction for investors.
For gold ore beneficiation, there are multiple stages including crushing, grinding, classification and separation. Firstly, by crushers, raw gold ores can be crushed into little particles. Next, those particles would be sent into grinding mills to be ground into fine powders. Finally, through specific beneficiation methods such as gravity separation and flotation, gold concentrates can be got. Finally, through other methods, users can get gold products they want.

Gold Ore crushing Process

Big gold ores are fed to the jaw crusher evenly and gradually by vibrating feeder through a hopper for primary crushing. After first crushing, the materials will be fed into cone crusher by belt conveyor for secondary crushing. Then, the brokenparticles will be transported to vibrating screen for classification. After classification, the particles that can meet requirements will be separated out as final products, while the remaining unqualified ones will be returned to cone crusher to have another crushing.This whole process can form a closed circuit.

100T/H-150T/H

250T/H-300T/H

650T/H-700T/H

1000T/H-1050T/H

NO.	Equipment	Model	Number
I	Hopper	LC3/LC4	1
II	Vibrating Feeder	F5X1045	1
III	Jaw Crusher	PE600x900	1
IV	Vibrating Feeder	GZD1200x2000	1
V	Cone Crusher	HST160 (H1)	1
VI	Vibrating Screen	S5X2160	1
VII	Iron-remover	RCYD-8	1

NO.	Name	Length(m)	Number
B1	B800	10+25	1
B2	B800	24	1
B3	B800	27	1
B4	B500	24	1
B5	B500	30	4

NO.	Equipment	Model	Number
I	Hopper	LC4	1
II	Vibrating Feeder	F5X1360	1
III	Jaw Crusher	PEW860	1
IV	Cone Crusher	HST250 & HPT300	1
V	Vibrating Screen	S5X2460-2	1
VI	Iron-remover	RCYD-10	1

NO.	Name	Length(m)	Number
B1	B650	19	1
B2	B800	9+39	1
B3	B800	9+23	1
B4	B1000	14+37	1
B5	B1000	22+29	1
B6	B650	9+30	1
B7	B650	30	1
B8	B1000	30	1
B9	B500	18	4
B10	B500	25	1

NO.	Equipment	Model	Number
I	Hopper	LC7	1
II	Vibrating Feeder	F5X1660	1
III	Vibrating Feeder	GZD1200X2000	7
IV	Jaw Crusher	C6X145	1
V	Cone Crusher	HST315(S2), HPT500(F1)*2	3
VI	Vibrating Screen	S5X3072-23,S5X2760-22, S5X2460-2	6
VII	Iron-remover	RCYD-12	1

NO.	Name	Length(m)	Number
B1	B1200	34	1
B2	B1200	26+29	1
B3	B1200	26	1
B4	B1200	29+78	1
B5	B1000	25+27	2
B6	B1000	26	2
B7	B800	22+27	1
B8	B1200	22+34	1
B9	B800	10+26	4
B10	B800	10+20	2
B11	B800	21	1
B12	B800	20	1
B13	B500	15	1

NO.	Equipment	Model	Number
I	Hopper	LC7	1
II	Vibrating Feeder	F5X1660	1
III	Vibrating Feeder	GZD1200X2000	1
IV	Jaw Crusher	C6X160	1
V	Cone Crusher	HST250(S1)2,HPT500(M)3	5
VI	Vibrating Screen	S5X3072-2*7,S5X2760-2	8
VII	Iron-remover	RCYD-12	1

NO.	Name	Length(m)	Number
B1	B1000	25	1
B2	B1000	25	1
B3	B650	8+65+26	1
B4	B1400	40	1
B5	B1200	25+27	1
B6	B1200	32	1
B7	B1400	40+90+20	1
B8	B1200	40+38	1
B9	B1200	36+50+26	1
B10	B1000	9+42+26	1
B11	B800	11+42+26	1
B12	B1000	11+43+26	1
