Gypsum Features

Gypsum is widely used as industrial and construction material. Usually, the gypsum includes plaster stone and anhydrite. Plaster stone is also known as hydrated gypsum and soft gypsum. Its structure is compact mass and threadiness and the Moh’s hardness of colorful plaster stone is 2. Anhydrite’s Moh’s hardness is 3-3.5. Its density is 2.8-3.0g/cm3. The two kinds of gypsum is companied by each other and transformed under some geologic conditions. They can be used in cement retarder, gypsum building product, model, medical food additive, vitriol production, paper filler and paint filler, etc..

Gypsum crushing Process

Passing through a hopper, raw gypsummaterials are fed by vibrating feeder into the jaw crusher evenly and gradually for primary crushing. After first crushing, broken materials will be transferred by belt conveyor to impact crusher for secondary crushing. The crushed gypsumparticles will then be transferred to vibrating screen for classifying. After classification, products in required size will be retained as final products, while the rest will be returned to the previous impact crusher for another crushing until getting all required sizes. In this way, the whole line completes a closed circuit crushing process. We can separate materials of different sizes according to users’ requirement.

150T/H-200T/H

350T/H-400T/H

550T/H-600T/H

800T/H-1000T/H

NO.	Equipment	Model	Number
I	Hopper	LC4*4M	1
II	Vibrating Feeder	F5X1045	1
III	Jaw Crusher	PE750x1060	1
IV	Impact Crusher	PFW1315III	1
V	Vibrating Screen	S5X2160-2,S5X1845-2	2
VI	Iron-remover	RCYD-8	1

NO.	Equipment	Model	Number
I	Hopper	LC4*4M	1
II	Vibrating Feeder	F5X1360,GZD1200x2000*2	3
III	Jaw Crusher	PEW860	1
IV	Impact Crusher	CI5X1520	1
V	Vibrating Screen	S5X2160-2,S5X2460-4,S5X2760-2	3
VI	Iron-remover	RCYD-10	1

NO.	Equipment	Model	Number
I	Hopper	LC6*6M	1
II	Vibrating Feeder	F5X1360,GZD2001203	4
III	Jaw Crusher	C6X125	1
IV	Impact Crusher	CI5X1520 , PFW1318III	2
V	Vibrating Screen	S5X2460-2*3, S5X2760-2	4
VI	Iron-remover	RCYD-12	1

NO.	Name	Length(m)	Number
B1	B800	18	1
B2	B650	20	1
B3	B500	20	1
B4	B1200	35	1
B5	B1200	26+25	1
B6	B1000	12+31	1
B7	B1200	10+42	1
B8	B650	10+25	1
B9	B650	10+31	1
B10	B650	31	3

NO.	Equipment	Model	Number
I	Hopper	LC7*7M	1
II	Vibrating Feeder	F5X1660,GZG750*3,GZG250	5
III	Jaw Crusher	C6X160	1
IV	Impact Crusher	CI5X1520*2,PFW1318III	3
V	Vibrating Screen	S5X2760-23,S5X3072-22	5
VI	Iron-remover	RCYD-14	1
