Copper Ore Features
Copper is mainly used in manufacturing of electrical equipment, construction such as roofing and plumbing as well as industrial materials such as thermal converter and alloys. The current copper alloys include bronze, brass (a copper-zinc alloy) and copper-tin-zinc alloy, etc.
For copper ore beneficiation, there are multiple stages including crushing, grinding, classification and separation. Firstly, by crushers, raw copper ores can be crushed into little particles. Next, those particles would be sent into grinding mills to be ground into fine powders. Finally, through specific beneficiation methods such as gravity separation and flotation, copper concentrates can be got. Finally, through other chemical methods, users can get final products they want.
Copper Ore crushing Process
Big copper ores are fed to the jaw crusher evenly and gradually by vibrating feeder through a hopper for primary crushing. After first crushing, the materials will be fed into cone crusher by belt conveyor for secondary crushing. Then, the brokenparticles will be transported to vibrating screen for classification. After classification, the particles that can meet requirements will be separated out as final products, while the remaining unqualified ones will be returned to cone crusher to have another crushing.This whole process can form a closed circuit.
| NO. | Equipment | Model | Number |
|---|---|---|---|
| I | Hopper | LC3/LC4 | 1 |
| II | Vibrating Feeder | F5X1045 | 1 |
| III | Jaw Crusher | PE600x900 | 1 |
| IV | Vibrating Feeder | GZD1200x2000 | 1 |
| V | Cone Crusher | HST160 (H1) | 1 |
| VI | Vibrating Screen | S5X2160 | 1 |
| VII | Iron-remover | RCYD-8 | 1 |
| NO. | Name | Length(m) | Number |
|---|---|---|---|
| B1 | B800 | 10+25 | 1 |
| B2 | B800 | 24 | 1 |
| B3 | B800 | 27 | 1 |
| B4 | B500 | 24 | 1 |
| B5 | B500 | 30 | 4 |
| NO. | Equipment | Model | Number |
|---|---|---|---|
| I | Hopper | LC4 | 1 |
| II | Vibrating Feeder | F5X1360 | 1 |
| III | Jaw Crusher | PEW860 | 1 |
| IV | Cone Crusher | HST250 & HPT300 | 1 |
| V | Vibrating Screen | S5X2460-2 | 1 |
| VI | Iron-remover | RCYD-10 | 1 |
| NO. | Name | Length(m) | Number |
|---|---|---|---|
| B1 | B650 | 19 | 1 |
| B2 | B800 | 9+39 | 1 |
| B3 | B800 | 9+23 | 1 |
| B4 | B1000 | 14+37 | 1 |
| B5 | B1000 | 22+29 | 1 |
| B6 | B650 | 9+30 | 1 |
| B7 | B650 | 30 | 1 |
| B8 | B1000 | 30 | 1 |
| B9 | B500 | 18 | 4 |
| B10 | B500 | 25 | 1 |
| NO. | Equipment | Model | Number |
|---|---|---|---|
| I | Hopper | LC7 | 1 |
| II | Vibrating Feeder | F5X1660 | 1 |
| III | Vibrating Feeder | GZD1200X2000 | 7 |
| IV | Jaw Crusher | C6X145 | 1 |
| V | Cone Crusher | HST315(S2), HPT500(F1)*2 | 3 |
| VI | Vibrating Screen | S5X3072-2*3,S5X2760-2*2, S5X2460-2 | 6 |
| VII | Iron-remover | RCYD-12 | 1 |
| NO. | Name | Length(m) | Number |
|---|---|---|---|
| B1 | B1200 | 34 | 1 |
| B2 | B1200 | 26+29 | 1 |
| B3 | B1200 | 26 | 1 |
| B4 | B1200 | 29+78 | 1 |
| B5 | B1000 | 25+27 | 2 |
| B6 | B1000 | 26 | 2 |
| B7 | B800 | 22+27 | 1 |
| B8 | B1200 | 22+34 | 1 |
| B9 | B800 | 10+26 | 4 |
| B10 | B800 | 10+20 | 2 |
| B11 | B800 | 21 | 1 |
| B12 | B800 | 20 | 1 |
| B13 | B500 | 15 | 1 |
| NO. | Equipment | Model | Number |
|---|---|---|---|
| I | Hopper | LC7 | 1 |
| II | Vibrating Feeder | F5X1660 | 1 |
| III | Vibrating Feeder | GZD1200X2000 | 1 |
| IV | Jaw Crusher | C6X160 | 1 |
| V | Cone Crusher | HST250(S1)*2,HPT500(M)*3 | 5 |
| VI | Vibrating Screen | S5X3072-2*7,S5X2760-2 | 8 |
| VII | Iron-remover | RCYD-12 | 1 |
| NO. | Name | Length(m) | Number |
|---|---|---|---|
| B1 | B1000 | 25 | 1 |
| B2 | B1000 | 25 | 1 |
| B3 | B650 | 8+65+26 | 1 |
| B4 | B1400 | 40 | 1 |
| B5 | B1200 | 25+27 | 1 |
| B6 | B1200 | 32 | 1 |
| B7 | B1400 | 40+90+20 | 1 |
| B8 | B1200 | 40+38 | 1 |
| B9 | B1200 | 36+50+26 | 1 |
| B10 | B1000 | 9+42+26 | 1 |
| B11 | B800 | 11+42+26 | 1 |
| B12 | B1000 | 11+43+26 | 1 |
